TP-LINK TL-SF1005P 5-Port 10/100Mbps Switch with 4-Port PoE+

5 × 10/100 Mbps RJ45 ports
4× PoE+ ports transmit data and power over individual cables
Works with PDs that comply with the IEEE 802.3af/at standard
Supports PoE power up to 30 W for each PoE port
Supports PoE power up to 67 W for all PoE ports*
Up to 250 m data and power transmission distance in extended mode
Priority mode gives high priority to ports 1–2 to ensure the quality of sensitive applications
PoE Auto Recovery ensures stable operation of PoE devices by automatically restarting failed or unresponsive PD devices
Plug and play with no configuration required

HARDWARE FEATURES
Interface • 5× 10/100 Mbps RJ45 ports (4× 10/100 Mbps 802.3af/at PoE+ ports)
• AUTOMATIC negotiation
• AUTO MDI/MDIX
Network media • 10BASE-T: Category 3, 4, 5 UTP cable (max. 100 m)
• EIA/TIA-568 100Ω STP (max. 100 m)
• 100BASE-TX: Category 5, 5e UTP cable (max. 100 m)
• EIA/TIA-568 100Ω STP (max. 100 m)
Fan quantity No fan
Physical security lock Yes
External power supply External power supply (output: 53.5 V DC / 1.31 A)
Packet forwarding rate 0.744 Mpps
PoE ports (RJ45) • Standard: compliant with 802.3 af/at
• PoE ports: Ports 1–4
• Power supply: 67 W
2K MAC address table
Jumbo frame 2 KB
Switching capacity 1 Gbps
Dimensions (W x D x H) 3.9 x 3.9 x 1.0 in (99.8 x 98 x 25 mm)
Maximum power consumption • 3.44 W (220 V / 50 Hz, with no PD connected)
• 74.49 W (220 V / 50 Hz, with 67 W PD connected)
Maximum heat dissipation • 11.73 BTU/h (without PD connected)
• 254.01 BTU/h (with 67 W PD connected)
SOFTWARE FEATURES
Store-and-Forward transmission method
Advanced features • Compatible with PDs compliant with IEEE 802.3af/at
• Automatic learning and automatic aging of Mac addresses
• IEEE 802.3x flow control
• Expansion mode button (ports 1–4, up to 250 m PoE power and data transmission)
• Auto PoE reset (ports 1-4)
• Priority mode button (ports 1–2)
OTHER
Certification FCC, CE, RoHS
Package contents • TL-SF1005P
• Power adapter
• Installation instructions
Environment • Operating temperature: 0–40 ℃ (32–104 ℉)
• Storage temperature: -40–70 ℃ (-40–158 ℉)
• Operating humidity: 10–90% RH non-condensing
• Storage humidity: 5–90% RH without condensation
